Laser Tuning:
- Tunable Wavelength Range: 1528 - 1566 nm
- Tunable Frequency Range: 191.50 - 196.25 THz
Laser Specifications:
- Parameter Min:
Optical Output Power(a): 12.5 dBm
Frequency Accuracy: -1.5 GHz
Tuning Resolution: -
Fine Tuning Resolution: -
Tuning Speed (Between Wavelengths): -
Fine Tuning Range: -30 GHz
Side Mode Suppression Ratio: 40 dB
Optical Signal Noise Ratio: 40 dB
Intrinsic Linewidth: -
Relative Intensity Noise: -
Back Reflection: -
Polarization Extinction Ratio: 18 dB
- Parameter Typ:
Optical Output Power(a): 13.5 dBm
Frequency Accuracy: -
Tuning Resolution: 50 GHz
Fine Tuning Resolution: 1 MHz
Tuning Speed (Between Wavelengths): 10s
Fine Tuning Range: -
Side Mode Suppression Ratio: 55 dB
Optical Signal Noise Ratio: 60 dB
Intrinsic Linewidth: 10 kHz
Relative Intensity Noise: -
Back Reflection: -
Polarization Extinction Ratio: -
- Parameter Max:
Optical Output Power(a): 14.5 dBm
Frequency Accuracy: 1.5 GHz
Tuning Resolution: -
Fine Tuning Resolution: 30 GHz
Tuning Speed (Between Wavelengths): -
Fine Tuning Range: -
Side Mode Suppression Ratio: -
Optical Signal Noise Ratio: -
Intrinsic Linewidth: 15 kHz
Relative Intensity Noise: -145 dB/Hz
Back Reflection: -14 dB
Polarization Extinction Ratio: -
(a) At the VOA Out Bulkhead
