Wavelength:
- Minimum: 775 nm
- Typical: 785 nm
- Maximum: 795 nm
Minimum Full Output Power: 20 mW
Setpoint Resolution: 0,1 mW
Laser Class: 3B
Fiber Type: 780HP
Mode Field Diameter (b): 5,0 ± 0,5 µm @ 850 nm
Numerical Aperture: 0,13
Output Fiber Connector: FC/PC, Wide 2.1 mm Key Compatible
Power Stability: 15 min: ±0.05 dB, 24 hr: ±0.1 dB (After 1 hr Warm-up at 25 ± 10°C Ambient)
Display Accuracy: ±10%
Adjustment Range: ~0 mW to Full Power
Input Power: 115 VAC / 230 VAC (Switch Selectable) 50 - 60 Hz
Modulation Input: 0 - 5 V = 0 - Full Power, DC or Sine Wave Input Only
Modulation Bandwidth:
- 5 kHz Full Depth of Modulation
- 30 kHz Small Signal Modulation
Environmental"
- Operating Temperature: 15 to 35 °C
- Storage Temperature: 0 to 50 °C
(b) Mode Field Diameter (MFD) is specified as a nominal value.
