LED Wavelength: 625 nm
Bandwidth (FWHM): 15 nm
Maximum Intensity at the Exit Port: > 0,4 mW
95% Intensity Clip Angular Span: ±7.35° (Minimum)
95%/50% Intensity Clip Bandwidth Ratio: >0.65
Standard Deviation within 95% Intensity Bandwidth Region: <1.5%
Exit Port Bulkhead: FC/PC, 2.2 mm Wide Key
NA: 0.22
Core Diameter: 200 µm
Operating Temperature (Non-Condensing): 0 to 40 °C
Storage Temperature: -40 to 70 °C
Risk Group(a): RG0
Compatible Patch Cables(b): M122L01 , M36L01 , M91L01
(a) According to the Standard IEC 62471:2006, Photobiological Safety of Lamps and Lamp Systems
(b) Other patch cables may be used that have identical core size, NA, and connector configurations, but performance may vary.
