Electrical Characteristics
Input Voltage Range: -10 V to +10 V
Input Impedance: 1 kΩ
Output Voltage: -200 V to +200 V
Output Impedance: 50 Ω
Slew Rate: 400 V/μs
Output Noise: 1.5 mV (RMS)
Voltage Gain(a): -20 ± 2%
DC Bias Adjust: -200 V to +200 V
HV Monitor to Output Ratio
With Input Impedance of 50 Ω: 40:1 (Vout / 40 ± 6%)
With Input Impedance of >10 kΩ: 20:1 (Vout / 20 ± 6%)
AC Power: 115 V / 230 V, 50-60 Hz, 70 VA
(a) The voltage gain is inverted to preserve the high slew rate of the output amplifier (i.e., a -1 V input results in +20 V output).
