Center Wavelength (Min / Typical / Max) : 625 nm / 635 nm / 640 nm
Operating Mode : Low, High, Pulse
CW Output Power (High/Low) : >2.5 mW/1 mW
Pulsed Output Power (High/Low) : >2.5 mW/~0 mW
Pulse Frequency : 2 Hz, 50% Duty Cycle
Laser Class : 3R
Output Fiber : SM600
Fiber Connector : FC/PC
DC Input Voltage : 9 VDC, 2 A (9.2 VDC Max)
Battery Type : NiMH, 3.6 V
Battery Life : 12 Hours Max (In High Power Mode)
~45 Days (On Standby)
Battery Temperature Limits : -20 to 60 °C
Maximum Charge Time : ~100 Minutes
Battery Charge Temperature Range : 10 to 38 °C
Dimensions : 5.33" x 2.74" x 0.94"
(135.4 mm x 69.6 mm x 24 mm)
AC Adapter Input : 100 - 240 VAC, 0.48 A, 50 - 60 Hz
Max Power : 18 W
Output Voltage : 9 VDC, 2.2 A
