Width: 0.9 mm
Height: 0.3 mm
Length: 1.9 mm
Function: Multi Function
Input Type: Schmitt Trigger
Logic Type: Monostable Multivibrator
Output Type: 3-State
Unit Weight: 2.300 mg
Logic Family: LVC
Logic Function: AND, MUX, NAND, NOR, OR, XNOR, XOR, Buffer, Inverter
Mounting Style: SMD/SMT
Number of Gates: 1 Gate
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 1.65 V
Number of Input Lines: 5 Input
Number of Output Lines: 1 Output
Propagation Delay Time: 6.7 ns
Low Level Output Current: 32 mA
Operating Supply Voltage: 1.8 V, 2.5 V, 3.3 V, 5 V
High Level Output Current: - 32 mA
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
