Width: 4.5 mm
Height: 1.05 mm
Length: 5.1 mm
Function: Buffer/Driver
Polarity: Inverting
Logic Type: CMOS
Technology: CMOS
Output Type: Open Drain
Unit Weight: 57.200 mg
Logic Family: HC
Mounting Style: SMD/SMT
Input Signal Type: Single-Ended
Quiescent Current: 2 uA
Number of Channels: 5 Channel
Supply Current - Max: 2 uA
Supply Voltage - Max: 6 V
Supply Voltage - Min: 2 V
Number of Input Lines: 6 Input
Number of Output Lines: 6 Output
Propagation Delay Time: 115 ns at 2 V, 23 ns at 4.5 V, 20 ns at 6 V
Low Level Output Current: 5.2 mA
Operating Supply Current: 20 uA
Operating Supply Voltage: 5 V
High Level Output Current: - 5 uA
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
