Shutdown: No Shutdown
3 dB Bandwidth: 140 MHz
Amplifier Type: Voltage Feedback
Mounting Style: SMD/SMT
SR - Slew Rate: 105 V/us
THD plus Noise: 0.00003 %, 0.00006 %
Moisture Sensitive: Yes
Number of Channels: 1 Channel
Supply Voltage - Max: 36 V
Supply Voltage - Min: 9 V
Ib - Input Bias Current: 20 uA
Operating Supply Current: 7.5 mA
Vcm - Common Mode Voltage: 4.3 V to 14.3 V
Ios - Input Offset Current: 250 nA
Output Current per Channel: 200 mA
Vos - Input Offset Voltage: 1 mV
Maximum Dual Supply Voltage: 18 V
Minimum Dual Supply Voltage: 4.5 V
GBP - Gain Bandwidth Product: 180 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
In - Input Noise Current Density: 2.3 pA/sqrt Hz
en - Input Voltage Noise Density: 950 pV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 85 dB, 90 dB
PSRR - Power Supply Rejection Ratio: 105 dB
