Width: 7.52 mm
Height: 2.35 mm
Length: 12.82 mm
Features: Adj Current Limit, Shutdown
Shutdown: Shutdown
Input Type: Rail-to-Rail
Supply Type: Single, Dual
Unit Weight: 601 mg
Amplifier Type: Power Amplifier
Mounting Style: SMD/SMT
SR - Slew Rate: 40 V/us
Voltage Gain dB: 108 dB
Moisture Sensitive: Yes
Number of Channels: 1 Channel
Dual Supply Voltage: +/- 5 V, +/- 9 V
Supply Voltage - Max: 24 V
Supply Voltage - Min: 7 V
Ib - Input Bias Current: 100 pA
Operating Supply Current: 39 mA
Operating Supply Voltage: 7 V to 24 V, +/- 3.5 V to +/- 12 V
Output Current per Channel: 1.5 A
Vos - Input Offset Voltage: 20 mV
Maximum Dual Supply Voltage: +/- 12 V
Minimum Dual Supply Voltage: +/- 3.5 V
GBP - Gain Bandwidth Product: 17 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
In - Input Noise Current Density: 0.004 pA/sqrt Hz
en - Input Voltage Noise Density: 102.8 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 80 dB
PSRR - Power Supply Rejection Ratio: 100 dB
