Width: 3.9 mm
Height: 1.45 mm
Length: 4.9 mm
Features: Decompensated
Shutdown: No Shutdown
Supply Type: Single, Dual
Unit Weight: 187 mg
Mounting Style: SMD/SMT
SR - Slew Rate: 80 V/us
Voltage Gain dB: 83 dB
Number of Channels: 2 Channel
Dual Supply Voltage: +/- 3 V, +/- 5 V
Supply Voltage - Max: 12 V
Supply Voltage - Min: 5 V
Ib - Input Bias Current: 10 uA
Operating Supply Current: 4.3 mA
Operating Supply Voltage: 9 V
Output Current per Channel: 90 mA
Vos - Input Offset Voltage: 1.2 mV
Maximum Dual Supply Voltage: +/- 6 V
Minimum Dual Supply Voltage: +/- 2.5 V
GBP - Gain Bandwidth Product: 320 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
In - Input Noise Current Density: 1.5 pA/sqrt Hz
en - Input Voltage Noise Density: 1.6 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 100 dB
PSRR - Power Supply Rejection Ratio: 80 dB
