Accuracy: 1 %
Gain V/V: 200 V/V
Shutdown: Shutdown
Gain Error: 0.1 %
Input Type: Differential
Output Type: High Side, Low Side
Mounting Style: SMD/SMT
SR - Slew Rate: 2 V/us
Development Kit: INA2181EVM
Number of Channels: 2 Channel
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 2.7 V
Ib - Input Bias Current: 75 uA
Maximum Input Resistance: 2.5 kOhms
Operating Supply Current: 500 uA
Vcm - Common Mode Voltage: 12 V
Ios - Input Offset Current: 50 nA
Output Current per Channel: 8 mA
Vos - Input Offset Voltage: 100 uV
GBP - Gain Bandwidth Product: 105 kHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
en - Input Voltage Noise Density: 40 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 100 dB
