Width: 7.52 mm
Height: 2.35 mm
Length: 12.8 mm
Function: Buffer/Line Driver
Polarity: Inverting
Logic Type: CMOS
Technology: CMOS
Output Type: 3-State
Unit Weight: 500.700 mg
Logic Family: AC
Mounting Style: SMD/SMT
Input Signal Type: Single-Ended
Quiescent Current: 8 uA
Number of Channels: 8 Channel
Supply Current - Max: 8 uA
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 1.5 V
Number of Input Lines: 8 Input
Number of Output Lines: 8 Output
Propagation Delay Time: 82 ns at 1.5 V, 9.2 ns at 3 V to 3.6 V, 6.5 ns at 4.5 V to 5.5 V
Low Level Output Current: 24 mA
Operating Supply Current: 80 uA
Operating Supply Voltage: 1.5 V to 5.5 V
High Level Output Current: - 24 mA
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
