Manufacturer: TES
Model: TES-3012
Original: Taiwan
- Frequency Count, Diode Check & Beeper
- Peak/Data Hold
- Unit & Sign Display
- Current: (AC) 20/200/600/1,000A
- Voltage: (AC/DC) DC-1,000V; AC-200V/750V
- Frequency: (Hz) 2KHz
- Ohms: (Resistance) 200 Ω /20K
Datasheet/ Catalogue
A. General Measurement
Voltage (AC/DC)
Range DC - 1000V
AC - 200V/750V
Accuracy DC - 0.8% rdg + 2 dgts
AC - 1.2% rdg + 3 dgts
Resolution 1V(DC); 100mV (AC)
Input Impedance 10M W
Overload Protection DC1100V & AC800V
Current (AC)
Range 20/200/600A (1000A for TES-3012)
Accuracy 2% rdg + 5 dgts (50/60 Hz)
Resolution 10mA
Overload Protection 1000A
Ohms (Resistance)
Range 200 W /20K W
Accuracy 1% rdg + 2 dgts
Resolution 100m W
Overload Protection 350V DC/AC (Also for continuity & Diode)
Max Open Circuit Voltage 3.5V, 0.3V
Continuity Beeper
Sound Level below 100 W
Max Open Circuit Voltage 3.5V
Resolution Diode 1mV
Max Test Current 1.5mA
Frequency (Hz)
Range 2KHz
Accuracy 1% rdg + 2 dgts
Resolution 1Hz
Max Allowable Applied Voltage 350Vrms
Max Input Sensitivity 100mV
B: Peak hold measurement (23 o C +/- 5 o C<80%R.H.)
Current (AC)
Range 20/200/600A(1000A)
Accuracy 2% rdg + 10 dgts
Resolution 10mA
Overload Protection 1000A
Range 200/750V
Accuracy 1.5% rdg + 8 dgts
Resolution 100mV
Input Impedance 10M W
Overload Protection DC1100V & AC800V
Display 3-1/2 digit LCD, Maximum reading 1999
Power Source one 9V battery
Size & Weight 208mm(L)x65mm(W)x31mm(H) & 330g
Accessories Carrying Case, Test Leads, Battery & Instruction Manual
