Language:
Basic: English, French, German, Italian, Spanish
Extended: Czech, Portuguese, Romanian, Hungarian, Swedish, Russian
Asian: Japanese
Data output
On-screen: Up to 7 results per page, selectable on-screen graph with XZ axis
Printer: Output settings, results and high resolution profile graph
PC Connection: Full data analysis with TalyProfile
Dta storage
Internal: 100 measurement results, 1 raw profile
USB (4GB supplied):
>39,000 raw profiles,
up to 100,000 results per batch (>70 batches)
PC connection: Unlimited data storage
SPC / stats
Internal Optional: Min, Max, Mean, StdDev of stored results
USB (4GB supplied) Optional: ASCII export of all results for SPC
PC connection: Full SPC and tollerancing of all parameters using TalyProfile software
Battery
Charger: USB 5v 1A 110-240VAC 50/60Hz
Charging time: 4 hours
Battery life: 2000 measurements
Standby time: 5000 hours
InstantOn: Max. 1 sec from standby to ready to measure
Auto sleep function: 30 sec - 6 hours
Gauge:
Range: 200 / 100 / 10 um
Resolution: 100 / 20 / 10nm
Noise floor(Ra): 250 / 150 / 100nm
Repeatability(Ra): 1 % of value + noise
Pickup type: Inductive
Gauge force: 150-300 mg
Stylus tip radius: 5 µm (200 µin) / 2 µm* (80 µin) or 10 µm* (400 µin)
Measurement type: Skidded
Analysis
Filter cut-off: 0.25 mm / 0.8 mm / 2.5 mm
Filter type: 2CR / Gaussian
Evaluation length: 0.25 - 17.5 mm (0.01 - 0.70 in)
Max. X axis range: 17.5 mm
Speed
Measuring speed: 1 mm / sec (0.04 in / sec)
Returning speed: 1.5 mm / sec (0.06 in / sec)
