Gain: 31 dBi
VSWR: 2:1, 2:1
Style: I-Bar
Width: 68.23 mm
Height: 14 mm
Length: 202.23 mm
IP Rating: IP67
Impedance: 50 Ohms
Cable Type: 3 M RG174, 3 M TGC200 x 2
Application: Telematics, Transportation, Remote Monitoring
Unit Weight: 300 g
Cable Length: 3 m
For Use With: Cellular LTE, Metal GPS/GLONASS/Galileo, WiFi
Polarization: Linear, RHCP
Mounting Style: Adhesive Mount
Electrical Type: Active
Number of Bands: 3 Band
Center Frequency: 700 MHz, 850 MHz, 900 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2600 MHz, 2450 MHz, 5500 MHz, 1575.42 MHz, 1602 MHz
Mechanical Style: Module
Maximum Frequency: 5.85 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: RP-SMA Male, SMA Male
Protocol - GPS, GLONASS: Galileo, GLONASS, GPS
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, UMTS, EDGE, HSPA
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
