Gain: 2 dBi, 2 dBi, 2 dBi, 2 dBi, 2.5 dBi, 2.5 dBi, 3 dBi, 2 dBi
VSWR: 2.5, 2.5, 3, 2.5, 1.5, 1.5, 1.5, 2
Style: I-Pad Flex
Width: 58 mm
Height: 0.2 mm
Length: 67 mm
Impedance: 50 Ohms
Cable Type: 180 mm RF1.37
Application: Wide-band Application
Unit Weight: 2.410 g
Cable Length: 180 mm
Polarization: Linear
Power Rating: 5 W
Mounting Style: Adhesive Mount
Number of Bands: 2 Band
Center Frequency: 700 MHz, 850 MHz, 900 MHz, 1700 MHz, 1800 MHz, 1900 MHz, 2450 MHz, 2600 MHz
Mechanical Style: PCB Trace
Maximum Frequency: 2.7 GHz
Minimum Frequency: 700 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: U.FL
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, GPRS, WCDMA
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
