Gain: 2.5 dBi
VSWR: 2:1
Style: I-Bar Flex
Width: 4.1 mm
Height: 0.24 mm
Length: 5.9 mm
Impedance: 50 Ohms
Cable Type: 45 mm RF1.13
Technology: Bluetooth
Application: Wireless Application
Unit Weight: 1 g
Cable Length: 45 mm
Polarization: Linear
Power Rating: 2 W
Mounting Style: Adhesive Mount
Number of Bands: 1 Band
Center Frequency: 2.45 GHz
Mechanical Style: PCB Trace
Maximum Frequency: 2.5 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM, RFID
Antenna Connector Type: U.FL Female
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
