High frequency output: Maximum 50 W
Transducer normal: 10 to 40 W
Oscillation frequency range: 19.5 to 20.5 kHz
Turning: Automatically
Operation mode:
– PWM operation: Automatic output adjustment according to viscosity change of sample
– POW operation: Stable oscillation when change in viscosity or temp are small
Other functions:
– Timer operation (1 sec to 120 min)
– Programmed interval operation (ON: 3 to 60 sec, OFF: 1 to 60 sec)
Display: Real time output value %, Output value setting %, Output value when oscillation start (%), Oscillation frequency
Configuration: Main unit, Converter (Horn/Oscillation switch integrated)
Oscillation switch: Equipped in both Main unit and Converter (Optional foot switch can be used)
Dimensions (W×D×H): 122 × 288 × 283 mm
Weight: Approx. 4.5 kg
Power supply: AC 100 V/1 A
●Optional step type Micro Tip required for use. •The chips for the previous model VP-5S cannot be used.
The chips for this model can be used in the previous model VP-5S.
●The chips for this model cannot be used in the previous model VP-5.
