Cooling temperature: -75℃ (at no load) (*)
Trapping volume: Approx. 1000mL/time
Volume inside chamber: Approx. 4L (Inner dia. 160 x 205mm)
Vacuum gauge: Pirani vacuum gauge (Digital display)
Compressor: 250 W × 2 (Cascade refrigerating system)
Recommended vacuum pump: Oil-sealed Rotary Vacuum pump (Ultimate pressure below 50 Pa, Displacement above 100 L/min)
Vacuum hose connection port: For outer dia. φ22 mm (Rc 3/8 Thread on inner surface, Convertible to different dia.), a hose with an inner diameter of φ18 mm is basically used.
Vacuum release: Leakage port with filter on the side of the body (N2 Gas purge combined use, Hose attachment port, Pisco φ6 mm), automatically released by halting the vacuum pump.
Other functions: Hot gas defrosting (thawing in approx. 30 minutes, outlet for the vacuum pump interlocking (Max. 3 sockets, 9 A, with operation switch), service outlet (up to 2 sockets, 3 A) Ultimate pressure display function, Recorder output for the degree of vacuum pressure (0 to 5 V)function , Recorder output for degree of vacuum pressure (0 to 5V)
Dimensions/Weight: 380 x 500 x 805 Hmm, Approx. 75kg
Power supply: AC100V/9A /Max.19A(Need a step-down transformer)
Standard accessories: Power plug (20 A) × 1 pc, Table mat × 1 pc
