Temperature range: +5℃ above RT to +70℃
Rotational speed: 300 to 2000r/min (*1)
Vacuum release: Timer automatic release (also Manual)
Rotor rotation system: Magnet drive
Timer: 1min to 99h59min (Digitally)
Lid/Chamber material: Lid: PVC, Chamber: Stainless steel SUS304 (Teflon coated)
Vacuum gauge: 0 to -0.1MPa (Bourdon tube)
Suction nozzle outer dia.: Rc 1/2 (φ13.8mm)
Sterilization filter: 0.2μm
Other function: Pump switch interlocking outlet × 1 (to 7 A)
(The Pump starts after reaching 85% of the preset rotational speed.)
Safe devices/protections: Overcurrent protection, Heater/Rotation/Pump is stopped when the Lid is open, High temp., Various indication (Nonvolatile memory, Temp. sensor, Heater output, High/Low temp., Motor, Rotational speed limit).
Dimensions/Weight: 310 (W) x 380 (D) x 343 (H)mm; Approx. 24kg
Power supply (*2): AC100V/2.7A /Max.10A(Need a step-down transformer)
