Standards: ISO 8041-2:2021; ISO 8041-1:2017; ISO 2631-1:1997; ISO 2631-2:2003; ISO 2631-5:2018
Meter Mode: aw (RMS whole-body), awmax (RMS max whole-body), VDV, MaxVDV, awv (vector whole-body), A(8) daily exposure, ELV time (time left to limit), EAV time (time left to action), MTVV, Max, Peak, Peak-Peak
Filters: Wd, Wk, Wm, Wb (ISO 2631) and corresponding band limiting filters according to ISO 8041
Motion Sickness Filter: Wf for measurements according to ISO 2631-1 (optional)
RMS & RMQ Detectors: Digital true RMS & RMQ detectors with Peak detection, resolution 0.1 dB
Measurement Range: 0.01 m/s² RMS ÷ 157 m/s² Peak
Frequency Range: 0.1 Hz ÷ 180 Hz
Data Logger: Time-history data including meter mode results and spectra
Time-Domain Recording: Simultaneous x, y, z time-domain signal recording (optional)
Analyser: 1/1 octave real-time analysis (optional) with center frequencies from 0.12 Hz to 128 Hz
1/3 Octave Analysis: Real-time analysis (optional) with center frequencies from 0.1 Hz to 128 Hz
Accelerometer: Built-in tri-axial MEMS based
Memory: 8 GB
Display: OLED 128 × 32 pixels
Interfaces: USB 2.0 client, Bluetooth wireless interface, operator presence detector
Power Supply: Ni-MH rechargeable cells, operation time > 24 hours¹
USB Interface: 500 mA HUB
Environmental Conditions: Temperature from -10 °C to 50 °C; humidity up to 90 % RH, non-condensed
Dimensions: Ø 235 mm × 12 mm
Weight: Approximately 500 grams
