Dimension：LxWxH(mm) 4350×1422×1750
Weigh: Approx.1600kg
Power Supply: 3PH 380V 50HZ
Startup Power: 33KW
Operation Power Consumption: 8KW
Control System: PC+PLC
Spraying movement: Step motor
Spray Pressure: 0.2Mpa~0.4Mpa
Flux Flow Arrange: option
Auto Fill Flux: Standards
Exhaust: Top exhaust
Exhaust Ducting Diameter(mm): Φ250
Exhaust fan power: 750W
Preheating Mode: Convection / IR emitter
Control Mode; PID
Preheating Zone Number: 3
Preheating Length(mm): 1800
Preheating Temperature: Room temperature~200℃
Warm-upTime(min): Approx.12min (setting：150℃)
PCB Width(mm): 50~350
Convoyor Direction: L→R (Option：R→L)
Conveyor Speed(mm/min): 500~1800
Conveyor Height(mm): 750±20
Available Component Heigh (mm): Top 120, Bottom15
Conveyor Speed Control Mode: Frequency converter closed-loop stepless speed regulation
Fingers:Spring tablet finger /D-40 duckbill finger/double hook finger/heavy double hook finger, choose one.
Conveyor Angle: 4~7°
Type of solder Pot: Motor drive
Solder Pot Material: Casting Iron
Wave Height Adjustment Digital: Control by PC
Cooling Method: Forced air cooling, Option: water cooler
Heater Power: 13.5KW
Solder Pot Temperature: 300°℃
Solder Pot Capacity: Approx.480KG
Wave Drive Power: 180W*2 3PH 220VAC
Solder Pot Warm-up Time: Approx.150min(setting：250℃)
Temperature Control Mode: PID
Finger Cleaning System: Brush
