Optical fiber requirements:
Material: Silica glass
Fiber count/Profile types: Single/SMF(G.652),MMF(G.651),DSF(G.653),NZDSF(G.655),BIF(G.657)
Fiber diameter: Cladding
diameter: 125µm,Coating diameter: 250-1,000µm
Cleave length: 5-16mm for
single fiber
Standard performance
Splice loss (typical): SMF: 0.03dB,
MMF:0.01dB, DSF:0.05dB, NZDSF:0.05dB
Return loss (typical): 60dB or
greater
Splice time (typical): 6sec
(SM G652 Quick Mode)
Heating time: 12sec
(FPS-61-2.6 sleeve, S60mm 0.25 Quick Mode)
Splice & Heat cycles per battery
full charge: Approx. 250 (BU-17)
Fiber view &
magnification: 2 CMOS cameras observation, 140X (zoom 370X) for X and Y axis
view.
Proof test: 1.96 - 2.09N
Applicable protection sleeve:
60mm, 40mm & Sumitomo Nano sleeves
Programs
Splice programs: Max. 300, 16
are pre-optimsed, 284 editable by user
Heating programs: Max. 100, 27
are pre-optimsed, 73 editable by user
Functions
Splice image capture/ Splice
data storage: 200 images /10,000 splice data (internal memory only)
50,200/20,000 (with 16GB SD card)
Auto-start: Splice/Heating
Multi clamp: Provided, 250um, 900um tight & loose
bufer fiber, 2 & 3mm jacket cord and rectangular drop cable, 3.5mm round
drop cable
Size/Weight
Size: 126(W) x 154(D) x 83(H)
mm (without protrusion)
Weight: 0.9kg (without Battery)
/ 1.2kg (with Battery BU-17)
Monitor: 4.3" touch
screen color LCD display
Terminals:
USB port: USB 2.0 (mini-B
type)
Storage media: SD/SDHC memory
card MAX 32GB
Power supply:
AC input: AC100~240V, 50/60Hz
(ADC-15)
DC input: DC 10~15V
Battery pack: Li-ion 10.8V, 4.560mAh
(BU-17)
Electrode life: 6,000 arc discharges
Basic Accessories: AC adapter 1pc , AC power cord 1pc,
Battery pack BU-17 1pc, Quick reference guide 1pc, Carrying case 1pc, Working
tray 1pc
