Output
Noise Bandwidth: 10MHz ~63.0GHz
Attenuation Range: 0.0~60.0dB
Attenuation Step: 0.1 dB
Max. Output Noise: ≥3.0 dBm(10MHz ~ 6GHz)
Flatness (attenuation 0.0dB)
±2.0 dB(10MHz ~ 50MHz)
±2.0 dB(50MHz ~ 2GHz)
±2.0 dB(2GHz ~ 5.4GHz)
±2.5 dB(5.4GHz ~ 6.0GHz)
Output Impedance: 50Ω
General Characteristics
Interface: RS-232, USB(standard), GPIB(optional)
Power: AC 100V-240V, 50Hz~60Hz (1±10%),<15VA
Environment: Temperature 5℃ ~ 40℃, RH<80%
Dimension: 254×103×374mm
Weight: 4.2 kg
Standard Accessories
Power Cord: 1pcs
CD(Software+ User's Guide): 1pcs
Features
Gauss white noise with broadband standard could be generated
Uniform and controlled spetral density, no DC and excess noise
Simulate link noise in the UAV, navigation and satellite communication
Widely application in electronic countermeasures and electromagnetic compaction, BER test and CATV test
