Width: 3.7 mm
Height: 4.4 mm
Length: 4.7 mm
Unit Weight: 453.600 mg
Current Rating: 1.25 A
Mounting Style: Through Hole
Vf - Forward Voltage: 1.45 V
Holding Current Ih Max: 5 mA
Breakover Current IBO Max: 25 A
Gate Trigger Current - Igt: 200 uA
Gate Trigger Voltage - Vgt: 800 mV
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
Non Repetitive On-State Current: 25 A
Maximum Gate Peak Inverse Voltage: 8 V
Off-State Leakage Current @ VDRM IDRM: 5 uA
Rated Repetitive Off-State Voltage VDRM: 500 V
