Shutdown: No Shutdown
Topology: Single
Output Type: Rail-to-Rail
Unit Weight: 16 mg
Qualification: AEC-Q100
3 dB Bandwidth: 100 MHz
Amplifier Type: Wideband Amplifier
Mounting Style: SMD/SMT
SR - Slew Rate: 117 V/us
THD plus Noise: 0.1 %
Number of Channels: 1 Channel
Supply Voltage - Max: 12 V
Supply Voltage - Min: 4.5 V
Ib - Input Bias Current: 6 uA
Operating Supply Current: 9.8 mA
Vcm - Common Mode Voltage: 4.5 V to 10.5 V
Ios - Input Offset Current: 100 nA
Output Current per Channel: 55 mA
Vos - Input Offset Voltage: 800 uV
GBP - Gain Bandwidth Product: 65 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
en - Input Voltage Noise Density: 11 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 77 dB
PSRR - Power Supply Rejection Ratio: 75 dB
