Width: 4 mm
Height: 1.75 mm
Length: 8.75 mm
Gain V/V: 200 V/mV
Shutdown: No Shutdown
Topology: Quad
Input Type: Differential
Unit Weight: 259.200 mg
Qualification: AEC-Q100
Amplifier Type: General Purpose Amplifier
Mounting Style: SMD/SMT
SR - Slew Rate: 13 V/us
THD plus Noise: 0.01 %
Number of Channels: 4 Channel
Supply Voltage - Max: 36 V
Supply Voltage - Min: 6 V
Ib - Input Bias Current: 20 pA
Operating Supply Current: 1.4 mA
Vcm - Common Mode Voltage: - 12 V to + 15 V
Ios - Input Offset Current: 5 pA
Output Current per Channel: 40 mA
Vos - Input Offset Voltage: 3 mV
GBP - Gain Bandwidth Product: 3 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
en - Input Voltage Noise Density: 15 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 86 dB
PSRR - Power Supply Rejection Ratio: 86 dB
