Fall Time: 410 ns
Rise Time: 440 ns
Technology: Si
Unit Weight: 76 mg
Channel Mode: Enhancement
Configuration: Single
Qualification: AEC-Q101
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 172 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 158 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 150 ns
Typical Turn-Off Delay Time: 600 ns
Id - Continuous Drain Current: 120 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 1.27 mOhms
Vds - Drain-Source Breakdown Voltage: 40 V
Vgs th - Gate-Source Threshold Voltage: 2 V
