Rework Part
Input Voltage: AC 220V / 50 Hz / AC 110V / 60 Hz
Temperature Range: 100 – 500°C
Max Power Rating: 700 W
Air Blowing Device: Air pump
Air Flow: 23 L/min
Dimensions: L160 × W95 × H141 mm
Heating Element: SP853
Nozzle CW Unit: A1124 / A1130
Hot Air Gun Stand: SP858-1
Soldering Part
Input Voltage: AC 220V / 50 Hz / AC 110V / 60 Hz
Temperature Range: 200 – 480°C
Max Power Rating: 60 W
Temperature Stability: ±2°C
Output Voltage: AC 24V
Tip to Ground Resistance: < 2 Ω
Tip to Ground Potential: < 2 mV
Heating Element: SP1327
Compatible Tip: 900M / 900L Series
Soldering Iron: SPK907H
Iron Stand: SP506
● Compact design,light weight soldering iron and hot air blower meet various soldering demands and remove kinds of chips in repair work.
● 2 in 1 design,save work space and soldering and repair can work individually
● Hot air temperature and volume adjustable,ideal for QFP,SOP,PLLCC and SOJ chips removing.
● Micro control system,digital display,easy to work with
● Pulses heating method,protect heating element,hot air blower from overheating,thus prolongs the machine’s service life.
● ESD safe design,no damage will caused to sensitive components
