Temperature Range: 200 – 480°C
Temperature Stability (No Load): ±2°C
Tin Adjustable: Yes
Input Voltage: AC 220V
Power Consumption: 90 W
Tip to Ground Resistance: < 2 Ω
Tip to Ground Potential: < 2 mV
Feeding Speed: 14 mm/s – 35 mm/s
Feeding Volume (Auto Mode): 0.5 – 123 mm
Feeding Interval Time: 0 – 3.5 s
Wire Diameter Usable: 0.4 / 0.5 / 0.6 / 0.8 / 1.0 / 1.2 / 1.6 mm
Feeding Mode: Auto (1–9) / Manual (0)
● High frequency current heating ; Rapid heating and quick thermal recovery, suitable for lead free soldering. Many types of tips are available for replacements.
● Micro computer control; set temperature only by pressing keys; temperature calibrated digitally; more functions available, such as auto sleeping, auto shut-off.
● Auto and manual soldering wire feeding are optional. Using Imported motor, feeding speed, feeding volumes, interval time could be regulated.
●Two types of feeding hose optional, easy to use. Long hose suitable for 昀椀xed soldering.
● Pedal switch or manual switch to choose from. Soldering direction may be changed as needed and soldering can be agile and convenient
