Nominal force (KN): 630
Knock-out force (KN): 190
Max. working hydraulic pressure (Mpa): 25
Slide-stroke (mm): 500
Knock-out stroke (mm): 200
Max. Daylight (mm): 800
Slide speed
Descent (mm/s): 100
Working (mm/s): 20
Return (mm/s): 60
Effective area of table
Left-right (mm): 560
Front-back (mm): 500
Overall Size
Left-right (mm): 2400
Front-back (mm): 1400
Height above ground (mm): 3100
Total motor power (kw): 7.5
Weight (kg): 3000
