Nominal Pressure (kN): 1600
Nominal Pressure Stroke (mm): 6
Stroke of Slide (mm): 180
Strokes
Variable (S.P.M): 30-55
Single (S.P.M): 50
Max. Die Set Height (mm): 400
Die Height Adjustment (mm): 100
Depth of Throat (mm): 390
Distance between Uprights (mm): 720
Size of Table
L-R (mm): 1170
F-B (mm): 760
Thickness (mm): 160
Size of Opening in Table
Diameter (mm): F180
Bottom Size of Slide
L-R (mm): 700
F-B (mm): 580
Hole for Punch Shank
Diamente (mm): F70
Depth (mm): 100
Single Speed Motor Power (kw): 15
Variable Motor Power (kw): 15
Overall Dimensions
F-B (mm): 2355
L-R (mm): 1515
Heigth (mm): 3250
Total Weight (kg): 13800
