Max. Swing over bed: 510mm
Max. Swing over cross slide: 300mm
Max. Swing in gap: 738mm
Distance between centers: 1500/2000mm
Spindle bore: 80mm
Taper of spindle bore: M. T. #7
Range of spindle speed: 25-1600rpm.
Range of longitudinal feeds: 0.059-1.646 mm/rev.
Range of cross feeds: 0.020-0.573Mm/rev.
Range of metric threads: 0.2-14mm
Range of inch threads: 2-112 TPI
Diametrical pitches range: 4-112D.P.
Module pitches rage: 0.1-7M.P.
Taper of tailstock bore: M. T. #5
Power of motor: 7.5kw
Packing dimensions: 2960 x 1130 x 1820mm
Net weight: 2335kg
Gross weight: 2700kg
