General capacity
Max.Swing over bed (mm): F356(14”)
Max.Swing over carriage (mm): F210(8-1/5”)
Max.Swing over gap (mm): F508(20”
Width of bed (mm): 260(10-1/5”)
Distance between centers (Two centers) (mm): 750(30”)/1000(40”)
Main spindle
Taper of spindle bore: MT-5
Diameter of spindle bore (mm): F40(1-1/2”)
Number of spindle speeds: 12
Range of spindle speeds (rpm): 0-1800
Spindle nose: D4
Threading & Feeding
Metric threads: 37kinds/(0.4-7mm)
23kinds/(0.45-7.5mm)
Whit-worth threads: 28kinds/(4-56T.P.I”)
40kinds/(4-112T.P.I”)
Range of longitudinal feeds (mm/r): 0.043-0.653(0.0012”-0.0294”)
Range of cross feeds (mm/r): 0.024-0.359(0.0004”-0.0103”)
Leadscrew
Diameter of leadscrew (mm): F22(7/8”)
Pitch threads of leadscrew: 4mm or 8T.P.I
Tailstock
Travel of tailstock quill (mm): 120(4-3/4”)
Diameter of tailstock quill (mm): F45(1-25/32”)
Taper hole of tailstock quill: MT-3
Power
Main motor power (KW): 2.4Kw(3HP),3Ph,4P,60Hz,230V
Coolant pump motor power (KW): 004Kw (0.055HP)
Overall dimemtions of lathe(LxWxH) (mm): 1900x710x1170
Packing size of lathe(LxWxH) (mm): 1900x760x1435
Net weight (Kg): 1200(2650 lbs)
Gross weight (Kg): 1300(2850 lbs)
