Open circuit output voltage: 6kV (Max) ±5％
Wavefront time: 1.2μs ±30％
Pulse half peak time: 50μs ±20％
Short-circuit output current: Up to 3kA ±5%
Pre-wave time: 8μs ±20％
Pulse half peak time: 20μs ±20％
Output polarity: Positive, negative, positive and negative cycles, positive and negative alternate, positive and negative first, negative and positive
Output impedance: 2Ω±10％
Surge trigger mode: Sync or asynchronous; Surges inject phase
Free set 0-360 degrees, resolution 1 degree
The way the surge is triggered: Automatic or manual, triggered at a single time
The number of surges: 1-9999 times
Programmable tester
Built-in IEC standards and user-defined programs for up to 1000 groups
Surge interval time: 20-9999s
Built-in surge voltage monitoring attenuation ratio: 1000: 1
Built-in surge current monitoring attenuation ratio: 1000: 1
Measurement accuracy: Better than 5%
Surge peak voltage, current display: LCD sync display
Surge voltage, current monitoring output: BNC coaxial terminals, ≥ 1M
EUT voltage, current monitoring parameters
LCD real-time display: AC voltage, current
Built-in network capacity
- AC: single-phase 300V, 10A (16AMax), 50/60Hz
- DC: 300V, 10A (16AMax)
Built-in network coupling
- Line-Line (L-N)
- Line-ground (L-PE, N-PE, L-N-PE)
Built-in network-coupled devices
- Line-line
- 18'F capacitor
- Line-ground
- 10-o resistance s.9 s. capacitor
- Use the environment: Temperature: 10%-75% relative humidity at 15C-35C
System power: AC220±10％，50/60Hz
Form factor: 470mm wide× 260mm high× 500mm deep
Weight of the whole machine: About 30kg
Product standards:
- GB/T17626.12
- IEC61000-4-12
- ANSI C62.41/ 45
- GB 18802.1
- IEC/EN 61000-4-5
- IEC/EN 61850-3
- ITU-T K.12
- ITU-T K.20
- ITU-T K.45
- UL1449
