Open circuit output voltage: 0.25-6kV ±5%
50Ω load output voltage: 0.125-3kV ±5%
Pulse shape: 5/50ns, 50Ω and 1000Ω load
Rise time:
- 5ns ±30%, 50Ω load
- 5ns ±30%, 1000Ω load
Pulse duration:
- 50ns±30%, 50Ω load
- 50ns-15/+100sn, 1000Ω load
Source impedance: 50Ω ±20%
Output polarity: Positive, negative, positive and negative cycle, alternating positive and negative, first positive and then negative, first negative and then positive
Pulse repetition frequency: 0.1－1200.0kHz ±10%
Burst length:
- standard: 15ms@2.5kHz/5kHz, 750μs@100kHz, 250μs@300kHz
- Adjustable: The number of pulses can be selected from 1 to 255
Pulse train length=(number of pulses-1)/pulse repetition frequency
Burst period: 100－999ms
Trigger mode: Synchronous or asynchronous;Sync phase
Freely set 0-360°, resolution 1°
Programmable test program: Built-in IEC standards and user-defined programs, up to 1000 groups
Built-in network capacity (Three lines and five lines)
- comminicate: Three-phase 380V, 30A (Max), 50/60Hz
- Direct current: 380V, 30A (Max)
Built-in network coupling: L1, L2, L3, N, PE, can be any combination
Built-in network coupling device: 33nF ±10% capacitive coupling
Use environment: Temperature: 15°C－35°C relative humidity 10%－75%
System power: AC220±10%, 50/60Hz, about 300W
Dimensions: 470mm wide × 215mm high × 500mm deep
Total Weight:About 25kg
Product Standard:
- IEC 61000-4-4
- IEC 61000-6-2
- IEC 61850-3
- GB/T 17626.4
- IEC 61000-6-1
- IEC 61326
- ANSI/IEEE C62.41
- EN 61000-4-4
- EN 61000-6-1
- EN 61000-6-2
- EN 61850-3
- EN 61326
- uIEC/EN 60601-1-2
