Gain: 3 dBi to 5.5 dbi
VSWR: 1.5
Style: Directional
Length: 180 mm
Diameter: 60 mm
Frequency: 698 MHz to 960 MHz, 1.2 GHz to 5.85 GHz
Impedance: 50 Ohms
Cable Type: 10 M RG58
Application: Cellular Applications, Wireless, Applications, ISM Applications
Unit Weight: 820 g
Cable Length: 10 m
Polarization: Vertical, Linear
Power Rating: 50 W
REACH - SVHC: Details
Mounting Style: Bracket Mount
Frequency Range: 698 MHz to 5.85 GHz
Number of Bands: 2 Band
Center Frequency: 700 MHz, 750 MHz, 800 MHz, 850 MHz, 900 MHz, 1200 MHz, 1700 MHz, 1800 MHz, 1900 MHz, 2200 MHz, 2450 MHz, 3500 MHz, 4200 MHz, 4500 MHz, 5000 MHz, 5500 MHz
Mechanical Style: Log Periodic
Maximum Frequency: 5.85 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM, RFID
Antenna Connector Type: SMA Male
Protocol - GPS, GLONASS: BEIDOU, Galileo, GPS
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN, WiMAX
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G/5G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, GRPS, PCS, WCDMA
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
