Gain: 6.78 dBi
Style: Tilt/Swivel
Width: 30.2 mm
Length: 196 mm
Diameter: 12.5 mm
Frequency: 850 MHz, 900 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 868 MHz, 915 MHz
Impedance: 50 Ohms
Application: Cellular Applications, ISM Applications
Unit Weight: 30 g
Polarization: Vertical
REACH - SVHC: Details
Mounting Style: Panel Mount
Frequency Range: 850 MHz to 2.1 GHz
Number of Bands: 4 Band
Center Frequency: 800 MH, 868 MHz, 900 MHz, 915 MHz, 1800 MHz, 1900 MHz
Mechanical Style: Whip
Maximum Frequency: 2.1 GHz
Minimum Frequency: 850 MHz
Termination Style: Connector
Protocol - Sub GHz: ISM
Antenna Connector Type: SMA Male
Protocol - WiFi - 802.11: LoRaWAN, SigFox
Maximum Operating Temperature: + 65 C
Minimum Operating Temperature: - 20 C
Protocol - Cellular, NBIoT, LTE: 2G/3G, Cellular (NBIoT, LTE), GSM, UMTS, DCS
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
