Gain: 2 dBi
VSWR: 2
Style: I-Bar
Width: 25 mm
Height: 7.7 mm
Length: 72 mm
Frequency: 824 MHz to 894 MHz, 1.71 GHz to 2.17 GHz, 2.4 GHz to 2.5 GHz
Impedance: 50 Ohms
Cable Type: 3 M RG174
Application: Cellular Applications, ISM Applications, Wireless Applications
Unit Weight: 50 g
Cable Length: 3 m
Polarization: Linear
REACH - SVHC: Details
Mounting Style: Adhesive Mount
Frequency Range: 824 MHz to 2.5 GHz
Number of Bands: 4 Band
Center Frequency: 868 MHz, 1.8 GHz, 1.9 GHz, 2.1 GHz, 2.45 GHz
Mechanical Style: Module
Maximum Frequency: 2.5 GHz
Minimum Frequency: 824 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: SMA Male
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G, Cellular (NBIoT, LTE), GSM, UMTS, GPRS
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
