Gain: 2 dBi
VSWR: 2
Style: Panel, Square
Width: 33.5 mm
Height: 5.5 mm
Length: 39.9 mm
Frequency: 824 MHz to 960 MHz, 1.71 GHz to 2.17 GHz
Impedance: 50 Ohms
Cable Type: 2.5 M RG174
Application: Cellular Applications, ISM Applications
Unit Weight: 40 g
Cable Length: 2.5 m
Polarization: Linear
REACH - SVHC: Details
Mounting Style: Adhesive Mount
Frequency Range: 824 MHz to 2.17 GHz
Number of Bands: 4 Band
Center Frequency: 850 MHz, 900 MHz, 1700 MHz, 1800 MHz, 1900 MHz, 2100 MHz
Mechanical Style: Module
Maximum Frequency: 2.17 GHz
Minimum Frequency: 824 MHz
Termination Style: Connector
Protocol - Sub GHz: ISM
Antenna Connector Type: SMA Male
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, GPRS, WCDMA
