Workpiece
Max. Mass: 400 g
Max. diameter: ø100mm
Mount table size: 110mm × 100mm
Mechanical unit
Balancing speed: 61,000min^-1/ 120,000min^-1
Bearing support system: Soft type
Measuring unit Balancing plane: 1 and 2 planes
Eccentricity correction: Included
Min. Achievable Unbalance: Depend on bearing performance of workpiece
Graphic display: 5.7" TFT color LCD with touch screen
Min. unbalance indication: 0.01mg
Indication mode: Polar coordinates and (3 to 99) components of unbalance vector(add or remove of unbalance correction masses are selectable)
No. of stored work data: 50 data (No limitation when use with USB memory)
Data transfer: Measured data can be transferred to PC or stored USB memory -optional
Others
Power supply: Single-phase AC100V
Dimensions: 260(W) × 450(L) × 430(H)mm
Mass: Approx. 26kg
Option
Printer: Micro-dot printer
Chuck: Pneumatic three-jaw chuck
Special function: Measurable up to 400,000 min^-1
