Workpiece
Max. Mass: 50kg
Drive system: Self drive
Mechanical unit
Balancing speed: 180 to 120,000min-1
Bearing support system: Soft type (cradle type)
Measuring unit
Min. Achievable Unbalance: Depend on bearing of work
Balancing plane: 1 and 2
Graphic display: 5.7" TFT color LCD with touch screen
Min. unbalance indication: 0.001mg
Unbalance measuring mod: Multi-speed multi-plane, Fixed-speed multi-plane
Monitoring items: Vibration, temperature
bearing diagnostic function: Including FFT
Indication mode: Polar coordinates and (3 to 99) components of unbalance vector (add or remove of unbalance correction masses are selectable)
No. of stored work data 50 data (No limitation when use with USB memory)
Data transfer: Measured data can be transferred to PC or stored USB memory -optional
Others
Power supply: 3-phase AC200V 50/60Hz
Dimensions: 950(W) × 550(L) × 1,200(H)mm
Mass: Approx. 200kg
Option: Dynamic response evaluation with non-contact displacement sensor (Lissajous waveform)
