Output channel: 4
Resolution: 1mV/1mA
CH1 Output : 6V/3.2A
CH2 Output : 32V/3.2A
CH3 Output : 32V/3.2A
CH4 Output : 6V/3.2A
Series : 60V/3.2A
Parallel: 32V/6.4A
Output power: 240W
Voltage programming accuracy: ±(0.03% of reading +10)mV
Voltage readback accuracy: ±(0.03% of reading +10)mA
Current programming accuracy: ±(0.3% of reading +10)mV
Current readback accuracy: ±(0.3% of reading +10)mA
Line/Load regulation (CV): 0.01% +2mV
Ripple and noise (CV): 5mV/ 350uVrms
Line/Load regulation (CC): 0.1%+3mA
Ripple and noise (CC): 2mArms
Line regulation (Series): 0.01% +5mV
Load regulation (Series): <100mV
Line regulation (Parallel): 0.01% +5mV
Load regulation (Parallel): 0.01% +50mV
Series/parallel/independent output: √
Timer display mode: √
Waveform display mode: √
Protection: OVP/OCP
Remote voltage compensation sense function: √
List Operation: Support List coupling function. In addition to setting up a single channel, you can also perform inter-channel coupling to meet the stable and controllable power-up sequence
Save/Recall: 8
Interface Capability: USB Device, USB Host, LAN, GPIB
Web Control: Web Server
Calibration: Calibrated before leaving the factory or Calibrated by user's instructions. (Two data types)
Display: 4.3' TFT-LCD (480*272)
Dimensions (WxHxD)mm: 221 x 133 x 300
Weight: 8kg
