SIGLENT SPD1305X Programmable DC Power Supply (30V/5A; 150W; 1mV/1mA)

DC Output (0℃ to 40℃)

- Output voltage: 0 to 30V

- Output current: 0 to 5A

Max output power 150W

Display:

- 2.8 inch true color TFT-LCD

- 5 digit voltage/4 digit current

Resolution: 1mV/1mA

Program accuracy (25±5℃)

- Voltage: ±(0.03% of reading +10mV)

- Current: ±(0.3% of reading +10mA)

Readback accuracy (25±5℃)

- Voltage: ±(0.03% of reading+10mV)

- Current: ±(0.3% of reading+10mA)

Temperature coefficient per ℃ (Output Percentage + Offset)

- Voltage: ±(0.01% of reading+3mV)

- Current: ±(0.01% of reading+3mA)

Constant voltage mode

- Load Regulation: ≤0.01% +2mV

- Ripple & Noise: ≤350uVrms/3mVpp (20Hz to 20MHz)

- Recovery time <50μs (50% load change, minimum load 0.5A)

Constant current mode

- Line Regulation: ≤0.2% +3mA

- Load Regulation: ≤0.2% +3mA

- Ripple & Noise: ≤2mArms

Power source: AC 100/120/220/230V ±10% 50/60Hz

Standard configuration interface: USB Device, LAN

Dimension: 154.6(W)×144.5(H)×280(D)mm

Weight: ≈5.5kg

Standard accessories

USB Cable: 1

Quick Start: 1

Calibration Certificate: 1

Power cord: 1

Output test Cord: 2 Sets
