Wavelength Range: 1260~1650nm
Calibrated Wavelengths: 1310/1490/1550/1625nm
Fiber Type: 9/125μm Singlemode
Attenuation Range: 2.5 - 60dB
Insertion Loss: <2.5dB
Max Input Power: +21dBm
Output Power Range (1): +18 ~ -55 dBm
Setting Time: <3s
Display Resolution: 0.01dB
Attenuation Accuracy : ±0.25dB @+25℃ ( Output power control mode)
Repeatability: ±0.25dB @+25℃
Return Loss: ≥55dB
Connector: FC(Interchangeable SC,ST)
Power Saving: Auto-off after 5 minutes idle
Backlight: Yes
Power Supply: Li-Ion Battery/AC Adaptor
Battery Life: Continuous operation >20 hours
Operating Temperature: -20℃ ~ 50℃
Storage Temperature: -40℃ ~ 70℃
Relative Humidity: 0~95% (non-condensing)
Weight: 345g (0.7 lbs)
Dimensions (H × W × T): 177×80×44mm (6.97×3.15×1.73 inch)
Note: (1) Input power level should be at least 3 dB higher than selected output power level;
Input power variations in frequency range <0.5 Hz
* Specifications subject to change without notice
Ordering Information
Standard Package Includes:
Instrument, Lithium battery, AC adapter, USB cable, OVA software CD, Soft carrying case, Warranty card, CE certificate, Certificate of calibration, User manual.
