ELECTRICAL
Determination of the Phase Presence
Nominal Voltage for Phase Presence
Indication (the voltage required for the
LCD L1, L2, L3 indicators to come on) From 40Vac to 500Vac.
Frequency range From 15Hz to 400Hz.
Determination of the Phases Rotary Field Direction:
Direction Indication by LCD Display(the
voltage required to have the LCD
Direction Arrows to indicates and the
L1 L2 L3 or L3 L2 L1 indicators to show) From 40 to 500Vac.
Frequency range From 15 Hz to 400Hz
Dimensions 150(L) × 72(W) × 33.8(D)mm
Material Poly carbonate / ABS
Weight
(less Soft pouch) Approx. 158.5g
