- Test voltage: 250V / 500V / 1000V
- Measuring ranges: 0-20MΩ / 0-200MΩ / 0-2000MΩ
- Accuracy
+ 0-2MΩ : ±(5%rdg+5dgt)
+ 0-20MΩ : ±(1.5%rdg+5dgt)
+ 0-200MΩ : ±(2.5%rdg+3dgt)
+ 0-2000MΩ : ±(5%rdg+5dgt)
- Resolution 0-20MΩ : 10kΩ
+ 0-200MΩ : 100kΩ
+ 0-2000MΩ : 1MΩ
- Measuring AC Voltage:0-600V
- Accuracy: ±(1.5%rdg+3dgt)
Test continued: yes
Dimensions: 175(L) × 85(W) × 75(D) mm
Weight: 600g
Power source: 1.5V (AA ) × 8
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| FEATURES | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ● Microprocessor-controlled. ● Measures insulation (MΩ), Continuity (Ω) and AC voltage. ● Three insulation test voltages(DC V) : 250V, 500V, 1000V. ● 3½ digital LCD (2000 counts). ● 68 × 34mm (2.677” × 1.338” ) large LCD display. ● Automatic circuit discharge. ● Test insulation at rated voltage into a 1mA load. ● 200mA short circuit testing current for continuity. ● Auto ranging. ● Fuse protection. ● Data hold function ● BS 16  edition. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
