Sensor: Analog Hall sensor
Nominal width: DN 32
Process connection: Female thread G 1¼ (further process connections available on request)
Metering range: 5...60 l/min For details see table "Ranges"
Pressure loss: ~1 bar at Qmax
Qmax: Up to 300l/min
Tolerance: ±8 % of full scale value
Pressure resistance: PS 200 bar
Medium temperature: -20..+85 °C optionally -20..+150 °C
Ambient temperature: -20..+70 °C
Media: Water
Materials medium-contact
Brass construction: CW614N nickelled, CW614N, 1.4305, 1.4310, hard ferrite
Materials, non medium-contact:
Electronic adapter: CW614N nickelled
Electronics housing: Stainless steel 1.4305
Glass: Mineral glass, hardened
Magnet: Samarium-Cobalt
Ring: POM
Supply voltage: 18..30 V DC
Power consumption: <1 W
Analog output: 4..20 mA / max. load 500 Ω or 0..10 V / min. load 1 kΩ
Switching output: Transistor output "Push-Pull" (resistant to short circuits and polarity reversal)
Iout = 100 mA max.
Hysteresis: adjustable, position of the hysteresis depends on minimum or maximum
Display: extendable graphic LCD display; Temperature range -20..+70 °C, 32 x 16 pixels, background illumination, displays value and unit, flashing LED signal lamp with simultaneous message on the display
Electrical connection: for round plug connector M12x1, 5-pole
Ingress protection: IP 67 (IP 68 when oil-filled)
Conformity: CE
Installation location
Standard: horizontal inwards flow; other installation positions are possible; the installation position affects the display, metering and switching range.
For details please see Datasheet
