Medium air / float PP
Metering tube: PSU
Switch: optional reed switch
Nominal width: DN 25
Process connection: malleable cast iron, female thread Rp 1''
Metering range: 3 – 25 Nm3/h
Qmax. : to 250 Nm3/h
Tolerance: ±3 % of the full scale value
Max. process pressure: 15 bar up to 25°C
Medium temperature: -20..+60 °C optionally +5..+100 °C measurement tube made from PSU
Ambient temperature: -20..+60 °C
Media: gases
Electrical data: see "Additional devices for GK / GKL"
Materials medium-contact: PA 6-3-T, Malleable cast iron , FPM float made from PP or s.s.1.4571 ,optionally, measurement tube made from PSU
