Dimension : 123 (H) X 65 (W) X 155 (D) mm
Weight: 2kg
Operating Voltage: DC : 24V ±10%; PoE : 36V~57V (Typical : 48V)
Flow Rate : 500mL/min (MAX 900)
Power Consumption : Approximately 5.0W
Measuring Type Display: Graphic LCD (160X100), Gas concentration, Flow rate, Alarm, Rear light, Device abnormality
Alarm : 90dB at 10cm
Relay: Primary Alarm, Secondary Alarm, Fault Alarm
Output Signal : Analog, 4-20mA
Digital Communication : RS-485, TCP Ethernet
Sampling Distance : Length of input gas tube : Up to 30m (FEP tube); Length of exhaust gas tube : Up to 30m (FEP tube)
Input/Output Tube: 1/4” Teflon tube
Operating Temperature: 0°C ~ 40°C
Control/Set: 4 Buttons & RS-485 & Ethernet
Remote Interface : Ethernet, RS-485
Wiring: 4 to 20mA / DC power / Relay : Up to 14 AWG
ETC: Update the latest version of firmware available via the web
Certification : EMC, RoHs2
